Mill Circuit Severe Duty Slurry pump – WSA(R)

The INDUX^®  WSA Slurry Pump series is particularly designed for the most aggressive applications like ball and Sag Mill cyclone feed, dredging and all coarse sand slurries and other harsh working conditions.

TheINDUX^®  WSA series are designed to pump highly concentrated slurries and slurries containing large particles which standard slurry pumps cannot deal with effectively. Making use of hard metal impellers & liners or hard metal Impellers combined with elastomer liners are optional in achieving maximum wear life whilst ensuring reduced maintenance costs.

Mineral Processing: Large suction and discharge sizes as well as a wide passage design are suited for sever applications such as mill discharge (cyclone feeds) in mineral processes. Hard Metal or elastomer liners are

optional in different processes which extend the life of the pump and reduce Total Cost of Ownership.

Coal Washing: A thick impeller and liner plus a wide passage allow large particles to pass through the pump. It is the ideal design for heavy media circuit/slurry in Coal Washing applications.

Harsh working conditions: weight concentration greater than 60%, median particle size greater than 3mm

Dredging: The use of hard metals and the inclusion of a specific large passage design makes the WSAS pump an outstanding performer in most gravel pump applications.
